PLT 300 Digital layout tool
New productItem #r4728599
Automated construction layout tool to speed-up jobsite stake-out using digital methods and BIM
- Distance measurement accuracy: ±3 mm + 10 ppm
- Operating distance range – of remote control (diameter): 5 - 328 ft
- IP protection class: IP 55 (EN 60529)
Customers also searched for construction layout tool, jobsite layout tool, construction layout, jobsite layout or laser layout tool
- One-person construction layout and measuring – digital layout tools cut the labor needed for construction staking in half, while significantly increasing the number of points possible in one day
- Get started faster – automatic stationing and tilt compensation for quick setup on the jobsite
- Digitized construction layout using green laser and tablet – simply tap the stake-out point you need on the controller, and the layout tool will localize it in reality using the motorized green laser pointer
- BIM-ready digital layout tool – bring the accuracy and efficiency of BIM-to-Field to your jobsites by switching to digital construction layout tools
- On the Hilti CPC battery platform – power this digital layout tool using the same batteries as all your Hilti 22V power tools (not compatible with Nuron batteries)
- Staking out 2D and 3D positions on the jobsite using digital CAD/BIM input
- Laying out formwork, positions for excavation and MEP fastening points on floors and ceilings
- Laying out single and dual slopes
- Laying out and transferring building control lines
- As-built measurement of existing features, including real-time area and volume calculations
- Product warranty against parts and manufacturing irregularities for 20 years
- After 2 years repair costs are capped
We manage your tools so you can manage your business.
- Loan tools during repair to reduce downtime.
- High-performing tools and latest technology help to increase jobsite productivity.
- Theft coverage helps to reduce financial risk and unexpected expenses.
- Free verification of tool accuracy in accordance with manufacturer’s specifications.
Technical Data
Documents
-
- Operating Instruction Li-Ion, Italian, Russian, Hebrew, Serbian, German, Swedish, Turkish, Ukrainian, Arabic, French, Portuguese, Finnish, Spanish, Norwegian, Polish, Lithuanian, Latvian, Romanian, Korean, Bulgarian, Slovakian, Japanese, Estonian, Croatian, Kazakh, English, Chinese, Danish, Czech, Hungarian, Dutch, Greek, Slovene, [ 1.5 MB ]
- Operating Instruction C 4/36 -90/-350/-DC (01), English, Spanish, French, Portuguese, [ 2.3 MB ]
Application videos
-
PL System - Advanced layout simplified.
-
PROMO video for PLC 400 Hilti Construction Layout - Ease of Use (EN)
-
PLT 300 positioning layout system.
-
PROMO video for Hilti Construction Layout - Technology Focus (EN)
-
PLT 300 positioning layout system.
